Home ProductsIndustrial sectional door

Sectional doors open vertically and are suspended under the ceiling, that the space outside and inside can be utilised

Certification
China Kunshan King Lift Equipment Co., Ltd certification
China Kunshan King Lift Equipment Co., Ltd certification
I'm Online Chat Now

Sectional doors open vertically and are suspended under the ceiling, that the space outside and inside can be utilised

Sectional doors open vertically and are suspended under the ceiling, that the space outside and inside can be utilised
Sectional doors open vertically and are suspended under the ceiling, that the space outside and inside can be utilised Sectional doors open vertically and are suspended under the ceiling, that the space outside and inside can be utilised

Large Image :  Sectional doors open vertically and are suspended under the ceiling, that the space outside and inside can be utilised

Product Details:
Place of Origin: CHINA
Brand Name: KING LIFT
Certification: CE
Model Number: KLSD4550-S
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: 638-2143USD/ea EXW
Packaging Details: exporting packing
Delivery Time: 15-20 days
Payment Terms: L/C, T/T
Supply Ability: 2000pcs/per month
Detailed Product Description
Open Style: Automatic/Manual Door Material: Sandwich Board 50mm,Both Side 0.5mm Galvanized Plate Steel
Surface Finishing: Finished With Coating Opening Way: Wall Switch And Pull Rope Control
Position: Logistic Warehouse Color: RAL9003 Standard, Other Colors Are Customized
Door Panel Height: Standard H=500mm Panel Thickness: 40±2mm,50±2mm,80±2mm
Panel Facial Pattern: Ribbed Wind Resistance: ≥700pa
Open Speed: 0.25m/S Max Width: W=11350mm

Industrial Overhead Sectional Door:

  1. Sectional door whatever from thermal efficiency and extreme durability to architecturally inspired models considering. It's the right garage door for your building application, including commercial, industrial, agricultural, and loading dock doors.
  2. Sectional garage doors are designed with horizontally split door panels that move vertically to open and then slide into horizontal tracks curved into the garage. As a result, the entire door sits parallel with the ceiling at a higher level than the door ordering height.
  3. Industrial overhead doors are commonly used in industrial and commercial settings, such as warehouses, loading docks, and distribution centers, as they are durable, secure, and can be customized to fit the specific needs of the space.

  4. Sectional garage doors are available in many different styles and colours which many customers have used to their advantage with endless design possibilities making their sectional door completely unique. Sectional garage doors come in 3 materials, steel, aluminium, and timber. Different designs and colors can be added, making it possible to match the door to your home's existing style. Sectional garage doors are also durable, energy-efficient, and noise-reducing due to their insulation features.

  5. As an experienced industrial doors manufacturer, King Lift door can provide high quality sectional industrial doors with competitive pricing.



Model No Size  Lift Type Control Way Pannel Thickness Voltage               Vision Window options Speed
KLSD3030-V W3000×H3000mm Verticle Lift Up Wall Switch 40±2mm 220V/380V              Non 0.25m/S
KLSD4040-S W4000×H4000mm Stand Lift  Up Pull Rope 50±2mm 220V/380V 660*330 1pcs 0.25m/S
KLSD4050-H W4000×H5000mm High Lift Up Remote 80±2mm 220V/380V 660*330  2pcs 0.25m/S

***Size:Max width W=11350mm, Other size can be customtized.

***Lit Type: Different lift type design based on :1. The height of door opening 2.The Height between floor level to ceiling
***Control Way:Standard is Wall Switch + Pull Rope. Others are options
***Pannel Thickness: Normally is 40mm±2, more thicker is better thermal insulation.
***Voltage: customized is available
***Vision Window Nos as customer requirements
***Safety Precautions:Wire rope breaking protection device, Spring breaking protection device...



*** Standard pannel H=500mm***

Sectional doors open vertically and are suspended under the ceiling, that the space outside and inside can be utilised 0



***VISION WINDOW Nos and MAN DOOR As customer's requirements to design***

Sectional doors open vertically and are suspended under the ceiling, that the space outside and inside can be utilised 1



***Industrial Door Structure***

Sectional doors open vertically and are suspended under the ceiling, that the space outside and inside can be utilised 2



Industrial Door Lift Up Type and Open Way:

Sectional doors open vertically and are suspended under the ceiling, that the space outside and inside can be utilised 3
